In tough working environments, two factors are put to constant test: friction, flexing, impact, moisture, dirt, and repeated mechanical stress. Stitching is arguably one of the most vital parts of many shoes, ranging from hiking boots to safety shoes to work boots, military boots, and outdoor shoes that help to put the various parts in place. In such applications merely selecting the sewing thread by tensile strength is not sufficient. The thread should have resistance to brushing and hold the seam, be flexible and dimensional, and perform consistently during the life of the product.
So it is very important to consider the type of shoe fabric, seam attachment, machine setup, and wear to make the right decision when choosing a sewing thread. Choosing the correct thread can help prevent seams, help increase the longevity of the product, decrease the chance of production flaws, and, most importantly, increase the likelihood of the satisfaction of the end-user.
Table of Contents
Understand the Abrasion Conditions
The first step is to get to know where and how the footwear will experience abrasion. It may be both internal, between the different layers of material and the thread, and external, along abrasive surfaces of stitched items.
See also:
The amount of stress depends on the variety of footwear used:
- Continued rubbing of hard surfaces may occur on safety and industrial footwear.
- Rocks, mud, moisture, and rough terrain can be an issue for hiking boots.
- Sports shoes are subject to repeated flexing along with friction.
- Military and tactical boots can be exposed to harsh outdoor environments.
- Work shoes do wear out from chemicals and dust and suffer intense mechanical usage.
Knowing the environment aids a manufacturer in deciding on the level of abrasion resistance, strength, flexibility, and chemical/moisture resistance needed.
Choose the Right Thread Material
The type of construction and the fiber type play a significant role in abrasion performance. Common footwear for demanding applications includes polyester sewing thread or nylon sewing thread or special high-performance thread constructions.
Polyester threads are used on a large scale due to their excellent ability to resist abrasion, dimension, moisture & UV. They can be used in various types of footwear for outdoor and general use.
The nylon thread is known for its high tensile property, has a high flex property, and has good repeated flex resistance. They may be especially beneficial in applications that need a dynamic seam movement.
However, in very heavy-duty situations, special threads like high-tenacity or bonded ones may be required. Bonding imparts thread properties that help it withstand high-speed sewing or its use and to eliminate the tendency to pull fibers apart through bonding.
The strongest thread available is not necessarily the best choice and should be determined as part of the design process.
Match Thread Size with Seam Requirements
The quality of seams on the thread depends on its width and size. If more mechanical resistance is required, use a heavier thread, but if it’s not needed, it may cause damage to the needle, bad stitches, too much tension, or damage to the material.
Manufacturers should consider:
- Material thickness
- Number of material layers
- Stitch type
- Required seam strength
- Needle size
- Machine capability
- Desired appearance
The goal is to have good seam performance without adding any undue stress on the shoe materials or seams.
Consider Abrasion Resistance Along with Flexibility
Hard and robust thread is not the only thing necessary for high-abrasion footwear. The thread should also have the ability to withstand flexing and bending often.
During normal wear a shoe seam can flex several thousand times. If it is too stiff, repeated flexing can cause stress concentrations, which may cause thread breaking or seam failure.
Focusing on Thread Finishes and Lubrications
The sewing performance is influenced a lot by thread finish. In the manufacture of shoes that are fast-moving, the threading passes through lengths of materials, a series of tension discs, a series of needles, and a series of guides. Too much tension on the thread causes heated or untightened strands.
Some of that can be helped by an appropriate finish:
- Reduce friction during sewing.
- Improve thread passage through machine components.
- Reduce thread breakage.
- Minimize needle heating.
- Improve stitch consistency.
- Support higher sewing speeds.
The finish, however, should be suitable for the subsequent finishes, thread, machine, and footwear material.
Match the Thread with the Needle and Machine
In the hands of a poor or inexperienced needle and machine operator, even the best thread can yield below-par performance.
Manufacturers should test the entire combination of thread and needles and the machine as a whole. If the needle is not the correct size, it may go through the glove, damaging the thread with each pass; if it is the wrong size, it could cause the thread to be too loose or too tight.
Manufacturers should consider the monitoring of:
- Thread breakage
- Skipped stitches
- Uneven stitch formation
- Needle heating
- Thread fraying
- Excessive tension variation
- Material damage
- Stitch consistency at production speed
Tests should be made in actual production conditions, not just in the lab.
Evaluate Seam Construction
Stitch design and thread cannot be decoupled. Abrasion resistance is affected by stitch type, number of stitches, seam allowance and location.
Too low stitch density may decrease the strength of the seams, and too high stitch density can lower the strength of the material, as there will be too many perforations generated during seaming.
The manufacturer should consider optimising the number of stitches based on the material and the use. The type and design of thread and stitched areas may also differ between high-stress and normal-stress areas like toe caps, heel sections, assemblies of eye-stays and reinforcement panels.
Conduct Abrasion and Durability Testing
Manufacturers should test the thread before it is approved for mass production under conditions that represent how the footwear is used.
Helpful assessments might include:
- Abrasion resistance testing
- Seam strength testing
- Flex-fatigue testing
- Washing and moisture exposure
- UV exposure where applicable
- Chemical resistance for industrial footwear
- Thread breakage during high-speed sewing
To select the best thread in a proper manner on a more reliable basis is to compare various thread constructions under the same conditions rather than only the tensile strength.
Choose Total Cost, NOT Thread Price
The list price may be lower, but in fact, a lower-cost thread may result in thread breaks, machine stoppages, rework, problems in the product, rejected footwear or early product failure.
When buying high-abrasion shoes, the total cost of ownership must be considered instead of the shoes’ price per cone or kg. Investing in a slightly higher quality thread that can enhance productivity and product durability can offer a greater return.
Conclusion
The selection of sewing threads for footwear for use in high-abrasion applications should be considered based on a holistic system approach. While tensile strength is significant, it is just one component. All of these factors must be taken into account simultaneously.
The ideal thread is one that not only survives demanding conditions but also performs consistently during manufacturing. By combining application-based thread selection with machine trials, seam testing, and continuous quality monitoring, footwear manufacturers can produce stronger, more reliable, and longer-lasting footwear while reducing production defects and unnecessary costs.
